Manitowoc Published 06-24-16, Control # 241-01 1-9
2250 OPERATOR MANUAL INTRODUCTION
1
CRANE WEIGHTS
NOTE: Weights may fluctuate ±3% due to manufacturing
tolerances.
Weight
Description Kilograms Pounds
LIFTCRANE
Rotating bed and undercarriage complete, counterweight, gantry, backhitch, fully rigged 21,3 m
(70 ft) boom No. 44 with one-piece butt and heavy lift top (including upper boom point, 272 t
(300 USt) block, and 14 t (15 USt) hook-and-weight ball), boom stops, and load lines
2250 SERIES 1 - - - - - - - - - - - - - - - - - - - 203 941 449,615
2250 SERIES 2 - - - - - - - - - - - - - - - - - - - 249 357 549,740
2250 SERIES 3 - - - - - - - - - - - - - - - - - - - 294 717 649,740
2250 SERIES 1 with RINGER prep - - - - - - - - 209 260 461,340
2250 SERIES 2 with RINGER prep - - - - - - - - 254 676 561,465
2250 SERIES 3 with RINGER prep - - - - - - - - 300 035 661,465
ROTATING BED MACHINERY MODULE
Rotating bed rear section, split rear drums with load lines, rotating bed pin pullers, boom hoist,
gantry, gantry lifting cylinders, equalizer, boom hoist line, operator’s cab, Cummins power plant,
hydraulic reservoir (full), and fuel tank (1/2 full) - - - - - - - - - - - - - - - - - - - - - - - - - 35 241 77,695
With RINGER prep - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38 070 83,930
ROTATING MODULE WITH CARBODY
Rotating bed front section with bearing turntable, swing drive, carbody with pin pullers, rotating
union, piping and installation, 12,2 m (40 ft) boom butt, and boom stops - - - - - - - - - - - - 31 508 69,465
With RINGER prep - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 33 999 74,955
Replace 12,2 m (40 ft) butt and boom stops with 3,7 m (12 ft) lower two-piece butt - - - - - - - 28 791 63,475
CRAWLERS
9 373 m (30 ft 9 in) crawler assembly with 1 219 m (48 in) treads (each) - - - - - - - - - - - - 24 412 53,820
UPPER COUNTERWEIGHT
Tray- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17 588 38,775
Lifting frame (each) (2 required) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 77 170
Center counterweight - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16 782 37,000
Lower side counterweight (6 on all SERIES) (each) - - - - - - - - - - - - - - - - - - - - - - 7 030 15,500
Upper side counterweight (2 on SERIES 2 and 4 on SERIES 3) (each) - - - - - - - - - - - - - 9 071 20,000
Upper power pin with cylinder (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13 30
Lower power pin with cylinder (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 20
Center couterweight lifting pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - 9 20
Total rotating bed counterweight - - - - - 2250 SERIES 1 - - - - - - - - - - - - - - - - - - - 76 747 169,200
2250 SERIES 2 - - - - - - - - - - - - - - - - - - - 94 891 209,200
2250 SERIES 3 - - - - - - - - - - - - - - - - - - - 113 035 249,200
LOWER COUNTERWEIGHT
Carbody center counterweight (2 on SERIES 2 and SERIES 3) (each) - - - - - - - - - - - - - 13 607 30,000
Carbody side counterweight (4 only on SERIES 3) (each) - - - - - - - - - - - - - - - - - - - 6 803 15,000
GANTRY
8 534 m (28 ft) gantry with polyamide sheaves - - - - - - - - - - - - - - - - - - - - - - - - 5 139 11,330
Backhitch (each leg) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 718 1,585
