INTRODUCTION 2250 OPERATOR MANUAL
1-10
Published 06-24-16, Control # 241-01
Counterweight handling link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40 90
BOOM NO. 44
12,2 m (40 ft) butt - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 903 8,605
9,1 m (30 ft) top (with lower point, wire rope guide) - - - - - - - - - - - - - - - - - - - - - 5 273 11,625
3,0 m (10 ft) insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 857 1,890
6,1 m (20 ft) insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 458 3,215
12,2 m (40 ft) light insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 927 4,250
12,2 m (40 ft) insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 458 5,420
9,5 m (31 ft 1-3/16 in) basic strap (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 192 425
3,0 m (10 ft) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - - - 79 175
6,1 m (20 ft) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - - - 133 295
12,2 m (40 ft) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - - 244 540
1,0 m (3 ft 4-3/8 in) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - 36 80
Intermediate suspension link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 29 65
14,5 m (47 ft 6 in) intermediate suspension pendant (each) - - - - - - - - - - - - - - - - - - 108 240
9,0 m (29 ft 5 in) intermediate suspension pendant (each) - - - - - - - - - - - - - - - - - - 79 175
3,0 m (9 ft 9 in) intermediate suspension pendant (each) - - - - - - - - - - - - - - - - - - - 47 105
Lower intermediate suspension link with pin (each) - - - - - - - - - - - - - - - - - - - - - - 27 60
Upper boom point (single sheave) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 421 930
Wire rope guide (on butt) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 948 2,090
Equalizer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 821 1,810
Strap link (attached to equalizer) (each) (4 required) - - - - - - - - - - - - - - - - - - - - - 11 25
Boom stop (each tube) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 374 825
NO. 132 JIB
6,1 m (20 ft) butt - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 462 1,020
6,1 m (20 ft) top (with jib point sheaves) - - - - - - - - - - - - - - - - - - - - - - - - - - - 855 1,885
6,1 m (20 ft) insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 362 800
12,2 m (40 ft) basic pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 79 175
5,8 m (19 ft 2 in) pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 52 115
Jib stop pendant and link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15 35
Jib stop strut and additional pendants (used with long reach boom top) - - - - - - - - - - - 38 85
6,1 m (20 ft) strut with sheave and links - - - - - - - - - - - - - - - - - - - - - - - - - - - 616 1,360
20,0 m (65 ft 7 in) backstay pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - 108 240
2,2 m (7 ft 4 in) backstay pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - 36 80
Backstay link (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 29 65
Backstay spreader - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 129 285
MACHINE OPTIONS
10,7 m (35 ft) elevated operator’s cab (increase over standard operator’s cab) - - - - - - - - - 1 982 4,370
10,7 m (35 ft) elevated operator’s cab with 1 321 mm (52 in) wide cab
(increase over standard operator’s cab) - - - - - - - - - - - - - - - - - - - - - - - - - 3 352 7,390
1 143 mm (45 in) wide front drum assembly - - - - - - - - - - - - - - - - - - - - - - - - - 2 807 6,190
1 854 mm (73 in) wider RINGER drum assembly (each) - - - - - - - - - - - - - - - - - - - 3 315 7,310
Gear case assembly for tandem drums (increase over standard) - - - - - - - - - - - - - - - 124 275
Luffing jib hoist assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 390 3,065
Second swing drive assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 811 1,790
Supplemental hydraulic reservoir for RINGER - - - - - - - - - - - - - - - - - - - - - - - - 136 300
Boom hinge pin pullers - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 179 395
RINGER attachment lugs on carbody - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 678 3,700
622 mm (24-1/2 in) diameter lagging for 1 143 mm (45 in) wide front or right rear drum - - - - 462 1,020
622 mm (24-1/2 in) diameter lagging for narrow left rear drum - - - - - - - - - - - - - - - - 192 425
Weight
Description Kilograms Pounds
