2250 OPERATOR MANUAL INTRODUCTION
622 mm (24-1/2 in) diameter lagging for 1 854 mm (73 in) wide RINGER drum (each) - - - - - 816 1,800
BOOM NO. 44 OPTIONS
9,1 m (30 ft) tapered insert (with wire rope guide) - - - - - - - - - - - - - - - - - - - - - - - 1 843 4,065
12,2 m (40 ft) long reach top (with lower point) - - - - - - - - - - - - - - - - - - - - - - - - 3 041 6,705
Rigging winch in butt - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 371 820
272 t (300 USt) load block with swivel hook - - - - - - - - - - - - - - - - - - - - - - - - - - 3 628 8,000
91 t (100 USt) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - - 2 177 4,800
55 t (60 USt) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - - 1 281 2,825
55 t (60 USt) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - - 2 007 4,425
14 t (15 USt) hook-and-weight ball (swivel) - - - - - - - - - - - - - - - - - - - - - - - - - - 566 1,250
SELF-ERECT OPTIONS
Rotating bed jacking system with pads - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 322 7,325
Carbody support pedestals - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 181 400
Crawler handling arrangement - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 195 430
3,7 m (12 ft) lower two-piece butt - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 934 4,265
8,5 m (28 ft) upper two-piece butt with wire rope guide - - - - - - - - - - - - - - - - - - - - - 3 354 7,395
Butt raising cylinder and installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 396 875
Assemble and rigging rope guides in butt - - - - - - - - - - - - - - - - - - - - - - - - - - - 950 2,095
27 t (30 USt) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - - 907 2,000
Rigging line—49 m (160 ft) of 28,6 mm (1-1/8 in) wire rope, 3,48 kg/m (2.34 lb per ft) - - - - - - 170 375
Rigging winch line—244 m (800 ft) of 9,5 mm (3/8 in) wire rope, 0,39 kg/m (0.26 lb per ft) - - - - 95 210
WIRE ROPE
Boom hoist—297 m (975 ft) of 26 mm (1 in) wire rope, 2,75 kg/m (1.85 lb per ft) - - - - - - - - - 818 1,805
Load lines—28,6 mm (1-1/8 in) wire rope, 4,01 kg/m (2.7 lb per ft) - - - - - - - - - - - - - - - 2 510 5,535
Whip line—387 m (1,270 ft) with heavy lift top - - - - - - - - - - - - - - - - - - - - - - - - - 1 555 3,430
Whip line—404 m (1,325 ft) with long reach top - - - - - - - - - - - - - - - - - - - - - - - - 1 623 3,580
Hoist line—625 m (2,050 ft) 29 mm wire rope, 4,25 kg/m (2.85 lb per ft) - - - - - - - - - - - - - 2 651 5,845
Whip line—387 m (1,270 ft) with heavy lift top - - - - - - - - - - - - - - - - - - - - - - - - - 1 642 3,620
Whip line—404 m (1,325 ft) with long reach top - - - - - - - - - - - - - - - - - - - - - - - - 1 712 3,775
Weight
Description Kilograms Pounds
To Next Page
