2250 OPERATOR MANUAL SETUP AND INSTALLATION
4
COMPONENT WEIGHTS
Table 4-1. Trailer Arrangements and Component Weights
Trailer
Arrangement
Component
Weight
kg (lb)
A
Rotating Bed with Operator’s Cab, Gantry, Equalizer, Self-Erecting Jacks, and
Unequal Split Rear Drums Without Lagging and Wire Rope . . . . . . . . . . . . . . . . . . .
Optional Items
Front Drum Without Lagging or Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD
Ringer Prep with Two-Full Width Drums and Lagging
Without Wire Rope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD
36 287 (80,000)
2 812 (6,200)
4 309 (9,500)
B
Undercarriage with Carbody and Adapter Frame, Turntable Bearing, One Swing
Drive, 3,66 m (12 ft) Lower Boom Butt, and Boom Butt Handling
Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional Items
Luffing Hoist with Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD
Ringer or MAX-ER Prep Second Swing Drive . . . . . . . . . . . . . . . . . . . . . . . . . ADD
29 211 (64,400)
2 177 (4,800)
816 (1,800)
C Crawler Assembly with 1,22 m (48 in) Treads . . . . . . . . . . . . . . . . . . . . . . . . EACH 25 265 (55,700)
D
9,14 m (30 ft) Boom Top with 9-Sheave Lower Boom Point, Wire Rope Guide, and
Basic Straps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional Items
Two Counterweight Side Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD FOR EACH
One Counterweight Side Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD
5 761 (12,700)
7 031 (15,500)
9 072 (20,000)
E
8,53 m (28 ft) Upper Boom Butt with Wire Rope Guide, and Boom
Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional Items
Two Counterweight Side Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD FOR EACH
27,22 t (30 USt) Assembly Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADD
5 194 (11,450)
7 031 (15,500)
907 (2,000)
