Manitowoc 2250 User Manual

Reference Only
SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-6
Published 06-24-16, Control # 241-01
6,05 m
CG
3,24 m
4,96 m
2,18 m
2,16 m
Load 13,16 m (43 ft 2 in) Long x 3,00 m (9 ft 10 in) Wide x 2,13 m (7 ft) High
Minimum Deck 1,07 m (3 ft 6 in)
(19 ft 10 in)
Maximum Deck 1,63 m (5 ft 4 in)
(7 ft 1 in)
(16 ft 3-1/4 in)
(10 ft 7-3/4 in)
(7 ft 2 in)
3,48 m
2,63 m
6,15 m
Maximum Deck
Load 8,81 m (28 ft 11 in) Long x 2,95 m (9 ft 8 in) Wide X 2,63 m (8 ft 7-1/2 in) High
Minimum Deck Height 61 cm (2 ft)
CG
1,08 m (3 ft 6-1/2 in)
(11 ft 5 in)
(20 ft 2 in)
(8 ft 7-1/2 in)
CG
4,32 m
(14 ft 2 in)
View C
1
View B
View A
A1045
FIGURE 4-4
If hydraulic tubing sticks up past the top of
the adapter frame, see Special Block
Requirements for more information.
Load: 9,37 m (30 ft 9 in) Long x 2,21 m (7 ft 3 in) Wide x 1,26 m (4 ft 1-1/2 in) High
