Manitowoc Published 06-24-16, Control # 241-01 4-7
2250 OPERATOR MANUAL SETUP AND INSTALLATION
4
13 cm
1,12 m
Load: 9,37 m (30 ft 9 in) Long x 2,21 m (7 ft 3 in) Wide x 1,26 m (4 ft 1-1/2 in) High
(5 in)
(3 ft 8-1/4 in)
Counterweight
1,91 m
2,90 m
Load: 10,06 m (33 ft) Long x 2,59 m (8 ft 6 in) Wide X 2,90 m (9 ft 6 in) High
CG
(6 ft 3 in)
(9 ft 6 in)
Side Box
Counterweight
3,45 m
4,93 m
Load: 11,94 m (39 ft 2 in) Long x 2,59 m (8 ft 6 in) Wide x 3,45 m (11 ft 4 in) High
CG
2,29 m (7 ft 6 in)
Assembly
Maximum Deck
MAXIMUM
(16 ft 2 in)
Side Box
Block
61 cm (2 ft)
(11 ft 3-3/4 in)
View E
View D
View C
2
A1045
FIGURE 4-4 continued
