Manitowoc Published 06-24-16, Control # 241-01 4-19
2250 OPERATOR MANUAL SETUP AND INSTALLATION
NOTE: The circled numbers in Figure 4-11 correspond to
the numbers of the following steps.
7. Make sure all four frame connecting pin latches are held
up with the latch pins (see View A).
8. Slowly retract the jacks to lower the adapter frame and
carbody back onto the trailer.
NOTE: Lower the front jacks first.
9. Continue to lower the rotating bed with the front jacks
until the front mounting holes line up with and engage
the two front frame connecting pins with the control on
the jacking remote. Then lower the rear jacks until the
rear mounting holes line up with and engage the two
rear frame connecting pins.
NOTE: The connecting pin latches should be able to drop
into the groove of the connecting pins when fully
installed.
10. Retain the frame connecting pins with latches and
secure the latches with latch pins (see View B).
11. Fully extend the jacks to lift the rotating bed, adapter
frame, and carbody off the trailer.
12. Remove the trailer.
CAUTION
Avoid Equipment Damage!
Do not lower the entire weight of the rotating bed onto the
adapter frame. Weight may exceed the trailer capacity.
