Manitowoc 2250 - Page 231

Reference Only
Manitowoc Published 06-24-16, Control # 241-01 4-69
2250 OPERATOR MANUAL SETUP AND INSTALLATION
4
6
5
1
2
Installed
2
Stored
5
4
3
1
10d
10e
10c
10a
10b
Item Configuration
1 Adapter Frame
2Pin (qty 2)
3 Screw with Lock Washer (qty 2)
4 Spacer (qty 2)
5Drum 5
6 Electrical Cable
7 Encoder
8a Air Line (pawl IN)
8b Air Line (pawl OUT)
9 Pawl Cylinder
10a Hydraulic Hose (brake release)
10b Hydraulic Hose (motor port A)
10c Hydraulic Hose (motor port B)
10d Hydraulic Hose (motor control)
10e Hydraulic Hose (case drain)
7
FIGURE 4-37
8b
8a
9
5
