Manitowoc 2250 - Page 238

Reference Only
SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-76
Published 06-24-16, Control # 241-01
Item Description
A Upper Connecting Hole
B Lower Connecting Hole
1 Fixed Vertical Pin
2 Removable Horizontal Pin with Cotter Pins
3 Washer (fixed vertical pin)
4 Retaining Pin with Cotter Pins
5 Removable Horizontal Pin with Cotter Pins—275 mm (10-27/32 in)
6 Strap Storage Pin
7 Connecting Pin
8Collar
9 Retaining Pin with Cotter Pins
10 Connecting Pin with Safety Pins
View A
View B
View C
View D
P837
P836
Heavy Lift
To p
Long Reach
Top
Transition
Insert
Intermediate
Suspension Link
Insert
Connector
Insert
Lug
Blocking
Outside
of Boom
Insert
Insert
Insert
Strap
Strap
Strap
Bracket
Strap
Links
Upper
Boom Point
A
B
Insert
View E
7
8
9
6
Stored
6
Stored
1
4
3
5
1
2
10
A1069
Boom Top
Boom Support
Strap
STOWED POSITION
OF STRAPS
WORKING
POSITION
OF
STRAPS
FIGURE 4-43
