SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-80
Published 06-24-16, Control # 241-01
Item Description
1 Strap Storage Pin
2 Connecting Pin with Collar and
Retaining Pin
3 Connecting Pin (equalizer to rails)
4 Stop Pin (equalizer)
5 Connecting Pin (links to equalizer)
6Collar
7 Retaining Pin
8Spacer
9 Pin (intermediate suspension pendant)
View F
View A
View B
View D
View C
S2 or
S3
Tagl i ne
Lug
Equalizer
Boom Butt
Wire Rope Guide
L2 or
L3
S2 or
S3
L1 or
L2
P843
P841
P844
Equalizer
L1 or
L2
Lug
L4 or
L5
P1
L4 or
L5
P1
P1
OR
85.3 m (280 ft)
Heavy Lift Only
All Other Boom Lengths
Heavy Lift and Long Reach
A1069
Boom
Strap
L2 or
L3
S2 or
S3
L1 or
L2
Rails
View E
Hole
A
Stored
1
9
5
8
5
Stored
3
4
7
6
8
2
1
P842
9
9
FIGURE 4-45
