SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-110
Published 06-24-16, Control # 241-01
Item Description Item Description
1 Link 7 Jib Stop Pendant—1,8 m (6 ft)
2 Link 8 Jib Stop Strut (long reach top only)
3 Jib Strut 9 Adjusting Link (5° offset only)
4 Spreader P1 Basic Jib Pendant—12,2 m (40 ft)
5 Basic Backstay Pendant—20 m (65 ft 7 in) P2 Jib Insert Pendant—5,8 m (19.2 ft)
6 Jib Stop Pendant—2,3 m (7 ft 7 in)
FIGURE 4-57
15° and 30°
Offset
P1 or P2
A1076
A1076
Boom
Top
Heavy
Lift Top
Lug
Boom
Top
Pin
Pin
Jib Butt
Pin
Pin
Long Reach
Top
Jib Butt
View E
View D
View C
View F
View G
Pin and
Collar
Pin
Pin
P1
A1080
Jib Top
A1076
Pin
Pin
5
4
2
3
1
A1080
6
9
6
9
5° Offset
9
9
8
6 7
4
5° Offset
9
6
7
8
5
View B
Pin
15° and 30°
Offset
Jib Butt
Jib Top
View A
Heavy Lift Top Shown
Long Reach Top Similar
9
Pin
Pin
Pin
