Manitowoc 2250 User Manual

Reference Only
SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-112
Published 06-24-16, Control # 241-01
FIGURE 4-58
Item Description
1 Basic Backstay Pendant—20 m (65 ft 7 in)
2 Backstay Pendant—2,2 m (7 ft 4 in)
3 Backstay Link—1,1 m (3 ft 8 in)
4 Connecting Link—0,3 m (12 in)
A1080
Jib
Point
View C
Long Reach
To p
5° Offset
15° Offset
30° Offset
5° Offset
15° Offset
30° Offset
View B
Heavy Lift Top
View A
Heavy Lift Top Shown
Long Reach Top Similar
Jib
Strut
Jib
Backstay
Link
A1076
A1076
4
3
4
2
2
1
4
1
1
4
1
4
3
1
2
4
1
3
