Reference Only
Manitowoc Published 06-24-16, Control # 241-01 4-121
2250 OPERATOR MANUAL SETUP AND INSTALLATION
4
Rope
Clips
P1519
Sucker
Line
FIGURE 4-67
A1189
Pad
Eye
Wire Rope
from Drum
Pad
Eye
Sucker
Line
Load Block Sheaves
(example)
Boom Point
Sheaves
Pull Sucker Line with
Winch or
Forklift Truck
B
D
F
A
G
C
No. 1.5 Pad Eye
Wire
Rope
E
Item
mm
in
A 16,00 0.63
B 6,35 0.25
C 25,40 1.00
D 11,18 0.44
E 28,70 1.13
F 4,06 0.16
G 33,27 1.31
