SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-138
Published 06-24-16, Control # 241-01
FIGURE 4-79
View A
Without
Luffing Hoist
A769
Item Description
1a Tie-Back Lug—1-3/4 in Diameter
1b Tie-Back Lug—1-5/16 in Diameter
2a Shackle—1-1/2 in
2b Shackle—1-1/8 in
3 Tie-Back Sling
4 Load Block
M
A
N
I
T
OW
OC
4
1a
2a
3
3
3
2b
1b
View B
With Luffing Hoist
