Manitowoc 2250 - Page 75

Reference Only
Manitowoc Published 06-24-16, Control # 241-01 3-9
2250 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Winch, Rigging (haul in rope)
Winch, Rigging (pay out rope)
Windshield Wiper (overhead
with washer)
Windshield Wiper (front
with washer)
FIGURE 3-1 continued
