Manitowoc Grove TMS9000-2 Series User Manual

4-57
TMS9000-2 OPERATOR MANUAL OPERATING PROCEDURES
4
Published 02-21-2019, Control # 611-05
GROVE
Switching off the main hoist
If you no longer require the main hoist, you should switch it
off to avoid unintentional use.
• Press the button (1, Figure 4-92) once.
- Symbol (2) is red when the main hoist is switched
off.
Auxiliary hoist
You can have the operating hours (1, Figure 4-93) of the
hoist displayed, refer to Operating hours menu, page 3-42.
Switching on the auxiliary hoist
After the ignition is switched on, all of the power units will be
switched off and the lamps in the corresponding buttons will
light up only dimly.
• Check whether the main hoist is switched off and
therefore secured against unintentional operation.
- Press the button on the right armrest (1,
Figure 4-94) once.Symbol (2) must be red.
Press the button on the right armrest (1, Figure 4-95) once.
Symbol (2) is green when the auxiliary hoist is switched on.
Check whether the current reeving of the auxiliary hoist is
displayed (Figure 4-96), e.g. 6. Correct the reeving if
necessary, refer to Entering the reeving, page 4-48.
Lifting and lowering
You can adjust the sensitivity of the control levers to suit the
operating conditions, refer to Setting the characteristic
curves for the control levers, page 4-84.
WARNING
Wire Rope Damage!
When both hoists are reeved, ensure that the ropes do not
rub or contact each other or the other hoist during
operation. Should this contact occur, the rope could be
damaged causing the rope to break, resulting in Death or
Serious Injury.
8854-129a
FIGURE 4-91
8854-128d
FIGURE 4-92
8849-89a
2
8849-96
FIGURE 4-93
8885-128e
FIGURE 4-94
8849-97a
2
8849-98a
FIGURE 4-95
8885-128e
2
8849-99a
FIGURE 4-96
