Routine Maintenance
223
7
Change Planetaries Oil
(Braked Axle)
STEP 1
DP97E395
Park the tractor on level ground and turn each
hub until the plug (1) is at the bottom.
STEP 2
Put a suitable size container under the plug.
Remove the plug. For best results drain the oil
when the oil is warm (after operation).
STEP 3
After the oil has drained, turn each wheel hub
until the plug is at the 3 or 9 o'clock position. Add
the recommended oil type until the oil is level
with the bottom edge of the plug hole. Wait
approximately 5 minutes for the oil to settle, then
check the oil level again and add oil if necessary.
STEP 4
Install the plug and tighten.
IMPORTANT: Dispose of oil and filters in
accordance with local regulations. DO NOT
drain the oil on the ground, into a drain or put
in a container that can leak. Be responsible
for the environment.
500 HOUR SERVICE
