Routine Maintenance
231
7
Change Cab Air Intake Filter
IMPORTANT: Respiratory protection equipment
and protective clothing appropriate to the
environment that the filter has been in contact with
MUST be used during the cleaning of the filter.
STEP 1
DP97A075 & DP96J439
STEP 2
MI03F036
Remove the old element(s) from the metal
retainer.
IMPORTANT:
The old element MUST be put into a
sealed container and disposed of in accordance with
local regulations. Be responsible for the environment.
STEP 3
MI03F037
Install the new element(s) into the retainer
making sure the rubber surround is pressed
firmly inside the retainer rim and the retaining
lugs are located in the slots in the retainer.
NOTE: Replace the element(s) with a genuine
McCormick part.
STEP 4
Installing the new filter element. Once securely in
place close the filter cover.
1000 HOUR MAIN SERVICE
Open the filter cover.
Push the catch down.
Remove the filter
element assembly
and clean the filter
housing.
1
