A-3.7 Graphic Commands
GRAPHIC COMMANDS Description
ESC * v # N Source Transparency Mode
ESC * v # O Pattern Transparency Mode
ESC * c # G Area Fill ID
ESC * v # T Select Current Pattern
ESC * c # W [data] Define User Defined Pattern
ESC * p # R Set Pattern Reference Point
ESC * c # Q User Defined Pattern Control
ESC * t # R Raster Graphic Resolution
ESC * r # F Raster Graphic Presentation
ESC * r # T Raster Graphic Height
ESC * r # S Raster Graphic Width
ESC * r # A Start Raster Graphics
ESC * b # Y Raster Graphic Y Offset
ESC * b # M Raster Graphic Compression Mode
ESC * b # W [data] Transfer Raster Graphic Data
ESC * B or ESC * C End of Raster Graphic
ESC * c # A Horizontal Rectangle Size, PCL Units
ESC * c # H Horizontal Rectangle Size, Decimal point
ESC * c # B Vertical Rectangle Size, PCL Units
ESC * c # V Vertical Rectangle Size, Decimal points
ESC * c # G Pattern ID for Area Fill
ESC * c # P Fill Rectangle Area
ESC * c # X HPGL Horizontal Picture Frame Size
ESC * c # Y HPGL Vertical Picture Frame Size
ESC * c 0 T HPGL Picture Frame Anchor Point
ESC * c # K HPGL Horizontal Plot Size
ESC * c # L HPGL Vertical Plot Size
ESC % # B Enter HPGL Mode
ESC % # A Return from HPGL to PCL Mode
