Microplex SOLID F44 - Ean 8 Sc2; Of 5 Interleaved

Appendix A Programming Guide
A-31
Example for 2 of 5 interleaved
type = 2 of 5 interleave: ESC * z 4 V
position = X=500; Y=500 ESC * p 5 0 0 x 5 0 0 Y
orientation = 90° ESC & a 9 0 P
text = actual font below ESC * z 4 Q
data = 1 2 3 4 ESC * z < 1 2 3 4 > Z
The HEXDUMP data stream for this example is:
1B 2A 7A 34 56 1B 2A 70 35 30 30 78 35 30 30 59
1B 26 61 39 30 50 1B 2A 7A 34 51 1B 2A 7A 3C
31
32 33 34 3E 5A
Print sample:
Example for EAN 8 SC2
type = EAN 8 SC2: ESC * z 1 0 2 V
orientation = 270° ESC & a 2 7 0 P
text = OCR-B below ESC * z 2 Q
data = 4 0 1 2 3 4 5 5 ESC * z 8 Z 4 0 1 2 3 4 5 5
The HEXDUMP data stream for this example is:
1B 2A 7A 31 30 32 56 1B 26 61 32 37 30 50 1B 2A
7A 32 51 1B 2A 7A 38 5A 34 30 31 32 33 34 35 35
Print sample:
