Microplex SOLID F44 - Printout of the Profiles

Configuring the Printer
3-4
--- Configuration (Default) ---> Profile 1 ---
MENU PAPER MENU PCL-MENU *)
TEAR OFF FORM PAPER = CUSTOM FONT NUMBER = 0
SELECT PROFILE = 1 PAPER LENGTH = 12 INCH PITCH = 10.00 **)
FEED N PAGES = 3 LENGTH FACTOR = 1 SYMBOL SET = ROMAN-8
SELECT FOLD IMAGE WIDTH = 8.50 INCH LINE SPACING = 6 LINES / INCH
CHANGE PROFILE ORIENTATION = PORTRAIT TOP MARGIN = 0 LINES
BASIC SETTINGS LANDSCAPE MODE = RESERVE LEFT MARGIN = 0 COLUMNS
TEST MODE ORIENT. MODE = FIXED RIGHT MARGIN = MAXIMUM
RESET PRINTER = NO PAPER EXTENDED = NO TEXT LENGTH = 72 LINES
PAPER SELECTION = ONLY PJL PERF SKIP = OFF
HUMIDITY = NORMAL
TONER DENSITY = MIDDLE
VER SHIFT = 0/100 INCH
HOR SHIFT = 0/100 INCH
INIT LINE REG. = 4
GENERAL MENU CONFIG.-MENU CLOCK MENU
EMULATION = PCL POWER SAVE = 15 MIN WEEKDAY = MONDAY
AUTO FORM FEED = OFF ALARMBELL = OFF DAY = 1
AUTO TEAR OFF = 30 SEC LANGUAGE = ENGLISH MONTH = AUGUST
TEAR OFF TIME = 10 SEC MENU ACCESS = ALL YEAR = 2011
TEAR OFF SHIFT = 0/24 SEC HOST CHANEL = PARALLEL ONLY HOUR = 14
PAPER RETRACT = ON RECAL FACTORY = NO MINUTE = 26
RESET TRU = NO SECOND = 34
EXCHANGE TRU = NO
TEST MENU INFOMENU
PANEL TEST PRINTER TYPE
= F44
SELF TEST ENGINE ID = 71XXXXXXXX-XX
TEST PRINT FIRMWARE VERS. = XXXXXXXXXX X.XXX
AUTO-TEST CONT. CPC-FPGA VERS. = X.X
PCL-TYPE LIST STACKER VERS: = X.XX X.XX
IC INFO = 15% USED
TRU INFO = 18% USED
FUSER INFO = 12% USED
MACHINE COUT = 884 PAGES
3.3 Printout of the Profiles
To printout the contents of all 50 Profiles use the same sequence as described in
paragraph 3.2.1 How to Start the SELF TEST up to point 6.
After selecting AUTO-TEST CONT, the printer starts to print all 50 Profiles.
Note: The text "Default" in the title indicates the currently selected profile.
Sample of PROFILE 1
*) Depending on setting of EMULATION in the GENERAL MENU (see TEST
PRINT) either PCL MENU or HEXDUMP MENU is indicated.
**) This value is depending on selected FONT NUMBER;
for FONT NUMBER 0, 39 - 44 = PITCH and
for FONT NUMBER 1 - 38 = POINT SIZE
See Paragraph 3.4 Menu Structure for the different entry points and Chapter
4 Explanation of individual Menu Items.
