Microplex SOLID F44 - USPS Intelligent Mail Barcode IMB

Appendix A Programming Guide
A-37
At system start and after a restart of the interpreter the module width will be
set to 5, the width will be 52 and the height 0. This leads to a default
selected barcode of 52 x 52 will a module size of 0,432 mm.
Example for USPS Intelligent Mail® Barcode IMB
type = USPS IMB (Standard)
ESC * z 2 4 0 V
data = 0123456709498765432101234567891
ESC * z <0123456709498765432101234567891> Z
CR LF LF 0D 0A 0A
MARK POLLMANN CR LF MARK POLLMANN 0D 0A
91 MAIN STREET CR LF 91 MAIN STREET 0D 0A
ANYTOWN MD 01234-5678 ANYTOWN MD 01234-5678
The HEXDUMP USPS IMB data stream for this example is:
1B 2A 7A 32 34 30 56 1B 2A 7A 3C
30 31 32 33 34
35 36 37 30 39 34 39 38 37 36 35 34 33 32 31 30
31 32 33 34 35 36 37 38 39 31 3E 5A
Print sample:
MARK POLLMANN
91 MAIN STREET
ANYTOWN MD 01234-5678
