Microplex SOLID F44 - Datamatrix

Appendix A Programming Guide
A-36
EXAMPLE for DATAMATRIX
type = DATAMATRIX ESC * z 2 3 0 V
module width = 0,423 mm (5/300”) ESC * z 5 S
position = X=500, Y=500 ESC * p 5 0 0 x 5 0 0 Y
height = 32 modules ESC * z 3 2 H
width = 32 modules ESC * z 3 2 W
data = PSi Engineering … ESC * z 6 0 Z PSi Engineering …
The HEXDUMP data stream for this example is:
1B 2A 7A 32 33 30 56 1B 2A 7A 35 53 1B 2A 70 35
30 30 78 35 30 30 59 1B 2A 7A 33 32 48 1B 2A 7A
33 32 57 1B 2A 7A 36 30 5A 50 53 69 20 45 6E 67
69 6E 65 65 72 69 6E 67 20 47 6D 62 48 0D 0A 45
69 73 65 72 66 65 6C 64 65 72 20 53 74 72 61 DF
65 20 33 31 36 0D 0A 35 37 30 38 30 20 53 69 65
67 65 6E 0D 0A
Print sample:
Notes: The supported Datamatrix barcodes are 10x10, 12x12, 14x14, 16x16,
18x18, 20x20, 22x22, 24x24, 26x26, 32x32, 36x36, 40x40, 44x44, 48x48,
52x52, 64x64, 72x72, 8x18, 8x32, 12x24, 12x36, 16x36, and 16x48.
Type, module width, height, and width may be omitted for the next barcode if
the value does not change.
If the barcode is a square then only the width may be sent.
If the number of data bytes sent is less than or equal to the maximum
number of bytes of the selected code minus the bytes needed to switch to
binary then binary coding will be performed. In other cases a code
dependent compaction will be done. If the compacted code does not fit into
the data area of the barcode then no barcode will be printed.
The error correction is ECC200.
Default Values
