MIMAKI CG-FX SERIES - Perform Plotting with a Perforated Line [POUNCING]

– 3.53 –
Perform plotting with a perforated line [POUNCING]
Pouncing is a perforated pattern. The pattern is as described below;
*Mark the perforated sheet with the marker or spray. It is useful for position-
ing of the signboard, formation of a construction, etc.
In order to create perforated pattern, pin (pouncing tool) and use a paper sheet, but a vinyl sheet.
Setting of the cutting conditions [PIN].
Setting value
OFF : The pouncing function is rendered ineffective.
ON : The pouncing function is rendered effective.
Setting of the pouncing conditions (Refer to Page 2.11 )
SPEED : 1 to 10cm/s(1cm/s step)
15,20,25,30,35,40,50,60,70,80, 90 100 cm/s
PRESSURE : 10 to 400(g)
Dot interval : 1 to 100 (mm)
Standard cutting
Pouncing
