– 3.63 –
Set the movement speed of carriage and sheet [UP SPEED]
This function is used to establish a traveling speed of the sheet and carriage to be employed when
the tool placed in the carriage is in the raised position.
If a lower speed is specified, displacement of the sheet will be eliminated at the time of long-dis-
tance feed.
Setting value
5, 10, 20, 30, 40, 50, 60, 70, 80, AUTO (cm/s)
• If the [AUTO] is specified, the SPEED setting established in the tool condi-
tions will be employed. It should be noted, however, the minimum SPEED
setting will be 10 cm/s.
Set the movement distance of carriage and sheet [JOG STEP]
This function is used to select the amount of travel of the carriage and sheet when the jog key (arrow
key) is pressed.
In the following cases, accurate positioning will be enabled.
• When performing two-point axis alignment.
• When performing digitization.
• When establishing an origin at a desired location with accuracy.
Setting value
For “mm”:
1.0: A press on the jog key will move the carriage and sheet by 1.0 mm.
0.1: A press on the jog key will move the carriage and sheet by 0.1 mm.
For “inch”:
1/16: A press on the jog key will move the carriage and sheet by 1.0 mm.
1/254: A press on the jog key will move the carriage and sheet by 0.1 mm.
