– 1.10 –
Control the clamp pressure
The clamp pressure can be changed in two levels using the clamp pressure lever. Select higher or
lower level of the clamp pressure that matches the sheet to be used.
*
Set the both clamp pressure is high mode when in using. If using the clamp in
a low mode, it may cause the misaligned sheet. Use the middle clamp in
need. (See below)
CG-75FX, CG-130FX
CG-160FX
High mode : Raise the clamp pressure lever.
Low mode : Lower the clamp pressure lever.
Clamp pressure
Application
High mode For cutting the sheet.
In the case where heavy-weight paper (70 kg or more) is used.
Low mode In the case where impressions of the pinch rollers should not be left on the sheet of media.
Depends on the sheet type, feed length, or the sheet width,
the sheet may be misaligned.
High mode : Raise the clamp pressure lever.
Low mode : Lower the clamp pressure lever.
