MIMAKI CG-FX SERIES User Manual

– 5.11 –
SQUARE CUT <ENT>
CT1 020 050 0.30
Functions
No. COPIES <ENT>
, ,
SET UP <ENT>
, ,
No. COPIES : 1
INTERVAL : 2mm
COMMAND <ent> COMMAND :MGL-IIc
1 ~ 999
0 ~ 30mm
AUTO, MGL-IIc, MGL-Ic1
INTERFACE <ent>
, ,
, ,
CUT MODE <ent>
, ,
ORGN SELECT <ent>
, ,
EXPANDS <ent>
, ,
AUTO. CUT <ent>
, ,
ROTATION <ent>
, ,
BUZZER <ent>
, ,
DIVISIONcut <ent>
BAUD RATE : 9600
PARITY : NONE
1200, 2400, 4800,
9600, 19200, 38400
7, 8
NONE, EVEN, ODD
HANDSHAKE :HARD
1, 2
HARD, ENQACK,
X-PRM, SOFT
DATA BITS : 8 BITS STOP BITS : 1
STEP SIZE : 0.05
3 ~ 60
0.01, 0.05, 0.25, 0.1
CLOSE TIME : 10s
CUT MODE:NORMAL
NORMAL, QUALITY,
HIGHspd
LOWERrightORIGIN
LOWERrightORIGIN,
CENTER ORIGIN
EXPANDS : OFF
ON, OFF
AUTO. CUT : OFF
ON, OFF
ROTATION : OFF
ON, OFF
BUZZER : ON
ON, OFF
DIVISION CUT: OFF
ON, OFF
CUT MARGIN : 30
0 ~ 50
, ,
To be followed
To be followed
FRAME CUT : OFF
ON, OFF
MARK CUT : OFF
ON, OFF
Enable to setting [DIVISIONcut] is [ON]
MARK DETECT<ent> MARK DETECT :OFF
OFF, 1pt, 2ptA, 2ptB,
3pt, 4pt
, ,
PAPER HOLD : ON
ON, OFF
DIST.REVI. : AFTER
OFF, BEFOR, AFTER
SIZE : 10mm
4 ~ 40
offsetA : 0.0mm
-40.0 ~ +40.0
offsetB : 0.0mm
-40.0 ~ +40.0
FORM : TYPE1
TYPE1 , TYPE2
COPIES A( ) : 1
1 ~ 9999
COPIES B( ) : 1
1 ~ 9999
Enable to setting [MARK DETECT] is not [OFF]
DEVICE No. <ent>
, ,
DEVICE No. : 0
0 ~ 99
3 STEP, 2 STEP
, ,
SKEW CHECK: 0
0 ~ 99
SPD LIMIT :0
0 ~ 60
1~ 50
CUT TYPE : 3 STEP
OVERLAP : 50mm
