– 2.12 –
Half cut conditions (HLF) settings
When the HARF settings is set to ON, the HLF is available to register the setting.
The following items are settable in the HARF settings.(
Page 3.52)
Half cut : Setting of broken-line cutting
Half cut press : Cutting pressure to remain after cutting
Half cut length : Length of sheet to remain after cutting
Cut length : Length by which the sheet is cut out.
Setting value
SPEED 1 to 10 cm/s (1 cm/s step)
15, 20, 25, 30, 35, 40, 50, 60, 70, 80, 90, 100 cm/s
PRESSURE 10 to 20 g (2 g step)
20 to 100 g (5 g step)
100 to 400 g (10 g step)
OFFSET 0.00 to 2.50 mm (0.05 mm step)
Operation Procedure
Refer to the Cut condition settings ( Page 2.9).
Select [HLF] in the step 1.
To Next Page
