– 3.60 –
Set the configurations with a computer [INTERFACE]
Set the communication condition with the RS-232C interface and the USB identification number.
Settings of the communication conditions differ with the command (AUTO, MGL-I c1 or MGL-II c)
specified using the command change-over function.
* If you have changed the step size, be sure to raise the pinch rollers using
the sheet set lever and re-load the sheet on the device.
Setting value
Baud rate 1200, 4800, 9600, 19200, 38400 (bps)
Data bit 7, 8 (bit)
Parity NON, EVEN, ODD
Stop bit 1, 2 (bit)
Handshake AUTO HARD
MGL-IIc HARD, ENQACK, X-PRM, SOFT
MGL-Ic1 HARD, XONOFF
Step size AUTO(MGL-IIc) 0.025 (mm)
AUTO(MGL-Ic1) 0.05 (mm)
MGL-IIc 0.025, 0.01 (mm)
MGL-Ic1 0.05, 0.1 (mm)
Close time *1) 3 to 60 (sec.)
*1) Close time
The minimum waiting time is required until the subsequent data is received.
The setting range is 3 to 60 seconds. If no data is received when the established waiting
time has elapsed after the completion of cutting, the device will judge that one piece of
data has completed to enable discrimination between the completed data and the subse-
quent data.
Guide to the establishment of close time.
• Breakpoint in object data to be cut by piece-cutting feature
Waiting time Required to start division-cutting
Waiting time retired to start outputting a sorting command
Set the each device number for a USB connection [DEVICE No.]
In case two and more plotters connected to a host computer with the USB cable, give the
different plotter number to the each plotter.
Setting value
DEVICE No. : 0 to 99
