– 5.2 –
Specifications of the main unit
Item CG-75FX CG-130FX CG-160FX
Acceptable sheet width mm inch mm inch mm inch
90 ~ 1040 4 ~ 40 90 ~ 1580 4 ~ 62 90 ~ 1880 4 ~ 62
Effective cutting area *1 760mm x 51m 1300 mm x 51 m 1600 mm *2 x 51 m
Automatic Cutting area *3 885mm 1425 mm 1720 mm
Maximum speed *4 140 cm/s (At 45 degrees direction with the pen up.)
Speed setting 1 ~ 10 cm/s (in 1 cm/s steps), 10 ~ 40 cm/s (in 5 cm/s steps)
(cutting/plotting) 40 ~ 100 cm/s (in 10 cm/s steps)
Mechanical resolution 5 µm (excluding expansion/contraction due to film temperatures)
Program steps 25 µm, 10 µm (MGL-IIc), 100 µm, 50µm (MGL-Ic)
Repeatability ±0.2 mm (excluding expansion/contraction due to film temperatures)
Guaranteed range of 760mm x 10 m 1300 mm x 10 m 1300 mm x 10 m
accuracy (repeatability) *5 (depending on the specified film and cutting conditions)
Maximum pressure 400 g
Cutter 10 ~ 20 g (2 g step), 20 ~ 100 g (5 g step), 100 ~ 400 g (10 g step)
Pressure setting Pin 10 ~ 20 g (2 g step), 20 ~ 100 g (5 g step), 100 ~ 400 g (10 g step)
Pen 10 ~ 20 g (2 g step), 20 ~ 100 g (5 g step), 100 ~ 150 g (10 g step)
Acceptable films PVC sheets (0.2 mm thick or less), fluorescent sheets *6, reflective sheets *6,
laminated sheets (0.2 mm thick or less)
Acceptable sheet for pouncing
Paper (thickness: 0.06 to 0.13 mm) *7
Applicable tools Cutters, water-ink ball-point pens, oil-ink ball-point pens, Commercial product for a
boll-point pen *8
Commands *9 MGL-IIc, MGL-Ic1
Interface RS-232C, USB
Receiver buffer 30 MB standard (20Mb when the sorting function is effective.)
Operating environment 5 to 35°C, 35 to 75 % (Rh) Non-condensing
Power capacity 220/240 VAC, 170 VA or less
Outside dimensions
(W) 1285 mm 1825 mm 2125 mm
(D) 610 mm 700 mm
(H) 1217 mm
Weight (With the legs attached)
50 kg 60 kg 66 kg
Noise *10 during discontinuous cutting (plotting) 49 dB (Absorption fan at low speed)
during continuous cutting (plotting) 60 dB (Continuous sounds)
*1: The maximum feeding length is restricted by the software to be used.
*2: When using four Pinch Rollers. In case using Pinch Roller 1 and Pinch Roller 2, the effective cutting
area is 1570 mm.
*3: The maximum speed may be restricted by the sheet size.
*4: The sheet width with the cut off function available.
*5: To achieve the guaranteed range of accuracy, the next page's requirements shall be satisfied.
*6: Provided that the blade specific to fluorescent sheets and the blade specific to reflective sheets are used.
*7: Pouncing tool intended specifically to pouncing shall be used.
*8: The commercial product between the 8 to 9 mm diameter. Accuracy and the quality of the image are
covered under warranty for the pen tip position differs according to the pen in use.
*9: When in use of the USB, the ESC type of the commands in the MGL-llc commands cannot be used.
*10: Standard measure of our products.
To Next Page
