– 1.7 –
Jog keys
The arrow keys are used as described in the table below.
Before the detection
of a sheet
Detects the sheet width
and the top end of the
sheet.
(In the case where a roll
sheet is loaded onto the
rear of the device)
Detects the width and
length of the sheet.
(In the case where a cut
sheet is loaded onto the
rear of the device)
Detects the sheet width
and the top end of the
sheet.
(In the case where a roll
sheet is loaded onto the
front of the device)
Detects the width and
length of the sheet.
(In the case where a cut
sheet is loaded onto the
front of the device)
When selecting a
function
Restores the last
previous function.
Moves to the next
function.
After the detection
of a sheet
Shifts and carriage to
the left.
Shifts the carriage to the
right.
Shifts the sheet away
from you.
Moves the sheet toward
you.
When inputting a
choice selected among
several alternatives
Selects the last
previous value.
Select the next function.
