– 3.3 –
1) Select the local mode.
Ascertain first the device does not cutting (plotting) under the REMOTE mode, then press the
[REMOTE] key to enter the LOCAL mode.
2) Press any of the jog keys[ ] [ ] [ ] or [ ] to switch to the jog mode.
Press any of the jog keys to enter the jog mode.
3) Select the jog function.
Select any of the [FEED], [DATA CLEAR], or [FUNCTION] key according to the settings.
4) Select parameters to determine the setting.
Select parameters for the functions: origin point setting, cut area setting, and the two point axis
alignment setting. Use the jog keys to select parameters.
5) Register/Perform the settings.
Push on the [ENTER/HOLD] key to register the setting values. Return to the local mode after
displaying the setting values for a little while.
Paper cutting function returns to the local mode after executing cut operation.
* In case specifying a point in the jog mode, the center of the tool indicates
the position regardless the light pointer on/off.
