TM80 Telemetry Monitor Service Manual 8-13
7. Remove the support for fixing the air tap and push out the air tap by using
tweezers.
8. Remove the two M1.6x3.5 cap head screws and pry up the integrated circuit
and pump from the side close to the battery compartment.
Remove the
support for fixing
Push out the air tap by
using tweezers.
Two M1.6×3.5 screws
Push
Pry up the pump
and integrated air
circuit from this side
