Image Optimization 5-53
Image zooming
Same as 3D/4D image zooming.
Hide/show reference image
The system displays 3 standard sectional images (A plane, B plane, C plane) in the
left side by default to indicate the position of the section lines; you can set [Ref. Img]
as “Off” to hide the 3 standard sectional images, and other images are displayed on
the whole image area.
Quick switch to single display
Select a certain image, double click <Set> key to enter into single display format, and
double click <Set> key again to return to the original display format.
Reset Orientation
Click [Reset Ori.] to reset the orientation and zoom status of the image.
Comment
Operations are the same as those in the other modes.
5.11 iScape
The iScape panoramic imaging feature extends your field of view by piecing together
multiple B images into a single, extended B image. Use this feature, for example, to view
a complete hand or thyroid.
When scanning, you move the probe linearly and acquire a series of B images, the
system piece these images together into single, extended B image in real time. Besides,
the system supports out-and-back image piecing.
After you obtain the extended image, you can rotate it, move it linearly, magnify it, add
comments or body marks, or perform measurements on the extended image.
You can perform the iScape panoramic imaging feature on B real time images using all
types of probes. The system also provides color iScape function, so that you can get
more information from extended images.
CAUTION:
iScape panoramic imaging constructs an extended image
from individual image frames. The quality of the resulting
image is user-dependent and requires operator skill and
additional practice to become fully proficient. Therefore, the
measurement results can be inaccurate. Exercise caution
when you perform measurements in the iScape mode.
Smooth even speed will help produce optimal image results.
Color iScape images are provided for reference only, not for
confirming a diagnosis.
Tips:
z iScape is an optional module, the function is available only if the module has
been installed on the ultrasound system.
z The display of the biopsy guideline is not allowed in iScape mode.
5.11.1 Basic Procedures for iScape Imaging
To perform iScape imaging:
1. Connect an appropriate iScape-compatible probe. Make sure that there is enough
coupling gel along the scan path.
2. Press the user-defined key on the control panel to enter iScape:
