5-2 Image Optimization
(1) Move the cursor to the item on the parameter area, and a frame will be around the
certain item, as .
(2) Press <Set> to adjust, and rotate the multifunctional knob to select the values.
îš„ Adjustment through control panel
z Trackball, control panel key, knob or sliders.
5.1.3 Quickly Saving Image Setting
Press <F7> to enter the image data saving dialogue box.
z Click [Save] to save the current image values for the current exam mode of the
certain probe.
z Enter the name in the box after the Save As to assign a name for a user-defined
exam mode, and click [Create] to save the current image parameters,
measurements, comments, body mark settings to the exam mode.
5.2 B Mode Image Optimization
B mode is the basic imaging mode that displays real-time images of anatomical tissues
and organs.
5.2.1 Basic Procedures for B Mode Imaging
1. Enter the patient information; select an appropriate probe and exam mode.
2. Press <B> on the control panel to enter B mode.
3. Adjust the parameters to optimize the image.
4. Perform other operations (e.g. measurement and calculation) if necessary.
îš„ Press <B> on the control panel to return to B mode in any time.
5.2.2 B Mode Parameters
îš„ In B mode scanning, the image parameter area in the upper left corner of the screen
displays the real-time parameter values as follows:
Parameter F D G FR DR iClear iBeam iTouch Zoom
Meaning Frequency Depth Gain
Frame
Rate
Dynamic
Range
Displayed when the function is
turned on.
5.2.3 B Mode Image Optimization
Gain
Description To adjust the gain of the whole receiving information in B mode. The real-
time gain value is displayed in the image parameter area in the upper left
corner of the screen.
