Image Optimization 5-1
5 Image Optimization
WARNING:
1. The images displayed in this system are only reference
for diagnosis. Mindray is not responsible for the
correctness of diagnostic results. It is the responsibility
of the clinician, who performs the exam, to capture the
correct diagnostic results.
2. In Dual-B imaging mode, the measurement results of the
merged image may be inaccurate. Therefore, the results
are provided for reference only, not for confirming a
diagnosis.
5.1 Imaging Mode
5.1.1 Switching Between Image Modes
Switch among the imaging modes according to the actual situation.
5.1.2 Image Adjustment
îš„ Adjustment through image menu
Press <Menu> or multifunctional knob to open the menu; use the trackball and <Set>
or the multifunctional knob to adjust.
îš„ Adjustment through soft menu controls
The soft menu locates at the bottom of the screen, items of which are dependent
upon image modes and preset. Take B mode adjustment as an example.
z Image mode switching
Use left / right controls of the four-directional key to switch among the modes.
The soft menu items vary depending on the mode. The menu navigation will
cause the change of the menu, while the change of the menu will cause the
menu navigation.
z Page up/down
Use the up/down keys of the four-directional key to turn pages up or down; you
can operate the items only when they are highlighted.
z Soft menu controls operation
a) The soft menu items are operated respectively through the five groups of
knobs.
b) You can also move the cursor to the certain soft menu item, and then press
<Set> or rotate the multifunctional knob to adjust.
îš„ Adjustment through image parameter area
The image parameter area is located in the upper left corner of the screen. The
image parameters are displayed while the image menu is not available.
