12-12 Setup
Tips: Usualy the DHCP is selected. If you select Static, please refer to 12.5.1 Local
TCP/IP to set IP Adres, Subnet Mask and Gateway.
4. Select the desired hotspot from the [Wireless Network Manager].
The data display in the [Network SSID] and [Security] control. If the hotspot wanted is
not in the list, you can input the data manually in the controls and click [Connect].
When connecting an encrypted network, enter the password in the box on the left
first.
5. If the connection is successful, the
will be displayed on the lower right corner of
the screen.
NOTE: 1. You can refresh the W-LAN network by switching the current adapter.
2. If the IP address displays as 0.0.0.0, this means that the network is
abnormal, the reason may be failure disconnection or the system cannot
obtain IP address.
3. The function of adding hotspot not displayed in the list by editing SSID,
Security and Password manually is not applied on software version
01.00.00.
12.5.2 iStorage
Enter [Preset]-> [Network Preset]-> [iStorage].
Name Description
Service Name Name of the device, cannot be empty
IP Address
IP address of the PC installed with iStorage software, cannot be
empty
To Next Page
