DICOM 11-13
b) Select a server in the Service List of Storage page and Storage Commitment page
and click [Default]; you can see “Y” is marked in the Default column.
c) Click [Exit] to exit the page and return to Setup menu, then click [Save] on the Setup
menu to make the preset to take effect.
(3) When finished the presets, you can perform image scanning, each time you press <End
Exam> on the control panel, the system will send the image to the default DICOM storage
server for storage and send storage commitment to storage commitment server.
If images are successfully sent to the storage server, the storage commitment server will
return information about the successful image storage. In the iStation screen, you will see
there is a tick “√” marked in the list below
.
Tips:
Storage commitment is confined to the whole exam; not each image sending can be indicated.
NOTE: Multi-frame storage is not allowed if “Allow Multiframe” is not selected ([Setup]→
[DICOM Preset] → [Set DICOM Service] → “Storage”). For example, if there is multi-
frame file in the exam to be sent, then only single-frame image storage will be
performed, and after the storage is completed, there is no “
” marked in the list below
in the iStation screen.
11.3.6 Query/Retrieve
The query/retrieve function is employed to query and retrieve the patient exam records in a
designated server.
After setting the DICOM query/retrieve server, you can perform the query/retrieve function in
iStation screen.
1. Open iStation screen: press <iStation> on the control panel; or, press <Info> on the control
panel, and then click [iStation] on the Patient Info screen.
2. Click [Query/Retrieve] to open the screen.
