11-2 DICOM
11.1.2 DICOM Local Preset
1. Enter the DICOM local preset screen through the path: [Setup]→[DICOM Preset].
2. Enter AE Title, Port, and PDU according to the actual situation, and then click [Save] to exit the
screen, setting items are introduced in the following.
Name Description
DICOM
Local
AE Title Application Entity title.
Port DICOM communication port.
PDU
Maximum PDU data package size, ranging from 16384 to 65536; if the
value is less than 16384 or greater than 65536, the system automatically
sets it to the value 32768.
Server
Setting
Device Name of the device supporting DICOM services.
IP Address IP address of the server.
Ping
You can ping the other machines after you entered the correct IP
address.
Besides, you can select a server in the Device list to ping it.
Device List Displays the added device.
Set DICOM
Service
Provides server settings of DICOM service, for details, please refer to the
following chapters.
Add Click to add server (s) to the Device List.
Delete Click to delete the selected server (s) in the device list.
îš„ Server setting procedure:
(1) Enter the server device name and IP address; click [Ping] to check the connection.
