5.3.3 When the communication unit is used
Use the following communication unit with the GOT to ensure compliance with the EMC Directive.
The GOT does not comply with the EMC Directive when connected with other than followings.
(Continued to next page)
Connection method Communication unit used
Hardware version of the communication unit
(Production year and month)
Bus connection
GT15-QBUS
Version D or later
(Oct., 2005)
GT15-QBUS2
GT15-ABUS
GT15-ABUS2
Version C or later
(Oct., 2005)
GT15-75QBUSL
GT15-75QBUS2L
GT15-75ABUSL
GT15-75ABUS2L
Version G or later
(Mar., 2005)
Direct connection to CPU
GOT RS-232 interface -
GT15-RS2T4-9P Version A or later
GT15-RS2-9P
GT15-RS4-9S
Version D or later
(Jan., 2006)
Computer link connection
GOT RS-232 interface -
GT15-RS2T4-9P Version A or later
GT15-RS2-9P
GT15-RS4-9S
Version D or later
(Jan., 2006)
MELSECNET/H
connection (PLC to PLC
network)
MELSECNET/10
connection (PLC to PLC
network)
GT15-J71LP23-25
GT15-J71BR13
Version C or later
(Sep., 2006)
CC-Link IE Controller
Network connection
GT15-J71GP23-SX
Version A or later
(Dec., 2007)
CC-Link IE Field Network
connection
GT15-J71GF13-T2
Version A or later
(Apr., 2011)
CC-Link connection
(Intelligent device station)
GT15-J61BT13
Version C or later
(Sep., 2006)
Ethernet connection GT15-J71E71-100
Version B or later
(Mar., 2005)
Microcomputer connection
(Serial)
GOT RS-232 interface -
GT15-RS2T4-9P Version A or later
GT15-RS2-9P
GT15-RS4-9S
Version D or later
(Jan., 2006)
Microcomputer connection
(Ethernet)
GT15-J71E71-100 Version B or later (Mar., 2005)
