2.1 Overall Configuration
2 - 1
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND
SETTINGS
5
EMC AND LOW
VOLTAGE
DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
2. SYSTEM CONFIGURATION
2.1 Overall Configuration
The overall configuration of GOT is as follows.
For the connection methods applicable to GOT1000 series and cable, refer to the following.
•GOT1000 Series Connection Manual for GT Works3 and a controller used
•GOT1000 Series Connection Manual for GT Designer2/GT Works2
Multi-color
display board
Personal computer
(Commercially available)
Extension unit
CF card
Memory card
adaptor
CF card
Memory
card
Option function
board
RS-422 conversion
unit
Battery
Protective sheet
Protective cover
for oil
Stand
Bar code reader
(Commercially available)
RFID controller
(Commercially available)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mitsubishi GOT1000 GT15 and is the answer not in the manual?

Mitsubishi GOT1000 GT15 Specifications

General IconGeneral
Display Size10.4 inches
Display TypeTFT Color LCD
Resolution640 x 480 pixels
Touch Panel TypeAnalog resistive film
Power Supply24V DC
BacklightLED
Protection RatingIP65 (front panel)
InterfaceRS-232, RS-422/485, USB
Operating Temperature0°C to 50°C
Memory9 MB
Storage Temperature-20 to 60°C
Display Colors256 colors
