13.7 Advanced Recipe Information
Before using advanced recipe information
For writing/reading into/from a controller with this function or editing of advanced
recipe file on the personal computer, refer to the following manual.
Specifications and operating procedure are described.
• GT Designer3 Version1 Screen Design Manual (Functions)
(24.3 Advanced Recipe Function)
• GT Designer2 Version Screen Design Manual
(12.3 Advanced Recipe Function)
13.7.1 Function of advanced recipe information
For the advanced recipe file used in advanced recipe function, copy/delete/file output are available.
In addition, it is possible to writing/reading into/from a controller by using this function, without creating the
screen to operate the advanced recipe. (Advanced recipe setting of GT Designer3 or GT Designer2 is
required.)
Function Description Refer to
Advanced
Recipe
Information
screen
Displaying file,
folder data
The file/folder name, data size and creating date & time are displayed. 13-47,13-49
G1P CSV
conversion
G1P file of advanced recipe file is converted to CSV file. 13-50
G1P TXT
conversion
G1P file of advanced recipe file is converted to Unicode text file. 13-50
Del File or folder is deleted. 13-52
Copy File is copied. 13-53
Move File is moved. 13-54
Rename File name is changed. 13-56
Create Folder New folder is created. 13-57
Create G1P New G1P file of advanced recipe file is created. 13-58
Advanced
Recipe
Record List
screen
Load record
GOT PLC
Selected record value is loaded in the device of controller. 13-60
Save record
PLC GOT
The device of controller is saved in selected record. 13-61
Match records
GOT PLC
Selected record is verified to the device value of controller. 13-62
Delete Device
Value
The device value contained in selected record is deleted. 13-64
