Mitsubishi GOT1000 GT15 - Operating the RGB Display Settings

11 - 43
11.12 RGB Display Settings
11.12.3 Operating the RGB display settings
11.12.3 Operating the RGB display settings
Precautions for setting
If the value for [Horizontal] or [Vertical] is too large, RGB display may not be
performed or the display may be disrupted or stopped.
If this happens, return the settings to their default values and make settings in the
range where RGB display is possible.
1 The clock phase and screen display
position (horizontal direction/vertical
direction) can be changed.
2 When touching the button, the
setting contents are determined.
3 If you touch the button without
touching the button, the dialog box
on the left is displayed.
4 After completing all the items to set, if you
touch the button, the display returns to
[Video/RGB Setting].
Changes the
number a
certain amount
in the
direction.
Changes the
number to the
touched
position.
Changes the
number a
certain
amount in the
direction.
Confirm
Confirm
