3.2 Performance Specifications
3.2.3 GT1575V-S, GT1575-S, GT1575-V, GT1575-VN, GT1572-VN
3 - 9
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND SETTINGS
5
EMC AND LOW VOLTAGE DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
3.2.3 GT1575V-S, GT1575-S, GT1575-V, GT1575-VN, GT1572-VN
(Continued to next page)
Item
Specifications
GT1575V-STBA,
GT1575V-STBD
GT1575-STBA,
GT1575-STBD
GT1575-VTBA,
GT1575-VTBD
GT1575-VNBA,
GT1575-VNBD,
GT1572-VNBA,
GT1572-VNBD
Display
section
*1
Type
TFT color liquid crystal (LCD of high intensity and wide angle
view)
TFT color liquid
crystal
Screen size 10.4"
Resolution 800 600dots 640 480dots
Display size 211(8.31)(W) 158(6.22)(H)[mm](inch)
Display character
16-dot standard font:
50 characters 37 lines (2byte character)
12-dot standard font:
66 characters 50 lines (2byte character)
16-dot standard font: 40
characters 30 lines (2byte character)
12-dot standard font: 53
characters 40 lines (2byte character)
Display color
65536 colors
*2
GT1575-VN:
256color
GT1572-VN:
16color
Display angle
Left/Right/Top/
Bottom:
85 degrees
Left/ Right/Top/
Bottom:
85 degrees
Left/Right: 45
degrees
Top: 30 degrees
Bottom: 20 degrees
Intensity of LCD only
400[cd/m
2
] 380[cd/m
2
]200[cd/m
2
]
Intensity adjustment 8-level adjustment
4-level
adjustment
Life
Approx. 50,000 h
(Operating ambient temparature: 25°C)
Approx. 41,000 h
(Operating ambient temparature:25°C)
Backlight
Cold cathode fluorescent tube (replaceable) backlight shutoff detection function is
included.
Backlight off/screen saving time can be set.
Life
*3
Approx. 40,000 h or longer (Time when display luminance reaches 50% at the
operating ambient temperature of 25°C)
Touch
panel
*7
Type Matrix resistive film
Number of touch keys
1,900 objects/screen
(38 lines 50 columns)
1,200 objects/screen
(30 lines 40 columns)
Key size
Minimum 16 16 dots (16 8 dots for the
last line only)(per key)
Minimum 16 16 dots (per key)
Number of objects
that can be
simultaneously
touched
Maximum of 2 objects
Life 1 million times or more (operating force 0.98 max.)

Mitsubishi GOT1000 GT15 Specifications

General

Display Size	10.4 inches
Display Type	TFT Color LCD
Resolution	640 x 480 pixels
Touch Panel Type	Analog resistive film
Power Supply	24V DC
Backlight	LED
Protection Rating	IP65 (front panel)
Interface	RS-232, RS-422/485, USB
Operating Temperature	0°C to 50°C
Memory	9 MB
Storage Temperature	-20 to 60°C
Display Colors	256 colors
