3.2 Performance Specifications
3.2.4 GT1565-V, GT1562-VN
3 - 13
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND
SETTINGS
5
EMC AND LOW
VOLTAGE
DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
3.2.4 GT1565-V, GT1562-VN
(Continued to next page)
Item
Specifications
GT1565-VTBA, GT1565-VTBD GT1562-VNBA, GT1562-VNBD
Display
section
*1
Type
TFT color liquid crystal (LCD of high
intensity and wide angle view)
TFT color liquid crystal
Screen size 8.4"
Resolution 640 480dots
Display size 171(6.73)(W) 128(5.04)(H)[mm](inch)
Display character
16-dot standard font: 40 characters × 30 lines (2byte character)
12-dot standard font: 53 characters × 40 lines (2byte character)
Display color
65536 colors
*2
16 colors
Display angle
Left/Right: 65degrees
Top: 50 degrees
Bottom: 60 degrees
Left/Right: 45degrees
Top: 20 degrees
Bottom: 20 degrees
Intensity of LCD only
380[cd/m
2
] 150[cd/m
2
]
Intensity adjustment 8-level adjustment 4-level adjustment
Life Approx. 41,000 h (Operating ambient temperature: 25°C)
Backlight
Cold cathode fluorescent tube (replaceable) backlight shutoff detection function is
included.
Backlight off/screen saving time can be set.
Life
*3
Approx. 40,000 h or longer
(Time when display luminance reaches 50% at the operating ambient temperature
of 25°C)
Touch
panel
*7
Type Matrix resistive film
Number of touch keys 1,200 objects/screen (30 lines 40 columns)
Key size Minimum 16 16 dots (per key)
Number of objects that
can be simultaneously
touched
Maximum of 2 objects
Life 1 million times or more (operating force 0.98N max.)
Human
sensor
Detection length None
Detection range None
Detection delay time None
Detection temperature None
Memory
*4
C drive
Built-in flash memory 9Mbytes
(for string project data and OS)
Built-in flash memory 5Mbytes
(for string project data and OS)
Life (Number of
write times)
100,000 times
