3 - 14
3.2 Performance Specifications
3.2.4 GT1565-V, GT1562-VN
*1 Bright dots (always lit) and dark dots (unlit) may appear on a liquid crystal display panel due to its characteristics.
It is impossible to completely avoid this symptom, as the liquid crystal display comprises of a great number of
display elements. Please note that these dots appear due to its characteristic and are not caused by product
defect.
*2 With the hardware version indicated below, it will be 256 colors when the multi-color display board is not installed.
For how to confirm the function version, refer to the following.
Appendix Confirming of Versions and Conformed Standards
Item
Specifications
GT1565-VTBA, GT1565-VTBD GT1562-VNBA, GT1562-VNBD
Battery GT-15BAT lithium battery (Option)
Backup target Clock data and maintenance time notification data
Life Approx. 5 years (Operating ambient temperature of 25°C)
Built-in
interface
RS-232
*6
RS-232, 1ch
Transmission speed: 115,200/57,600/38,400/19,200/9,600/4,800 bps
Connector shape: D-sub 9-pin (Male)
Application: For communicating with a controller or connecting a personal
computer (Project data read/write, OS installation, FA transparent function)
USB
USB (Full Speed 12 Mbps), Device, 1ch
Connector shape: Mini-B
Application: For connecting a personal computer (Project data read/write, OS
installation, FA transparent function)
CF card
Compact flash slot, 1ch
Connector shape: TYPE 1
Application: Data transfer, data storage, GOT startup
When formatting a CF card to FAT16: Up to 2GB
When formatting a CF card to FAT32: Not available
Option function board For option function board mounting, 1ch
Multi-color display board
For multi-color display board mounting,
1ch
Cannot be used. (Even installed, 65536
colors will not be displayed.)
Extension unit
*6
For communication unit/option unit mounting, 2ch
Buzzer output Single tone (tone length adjustable)
Protective structure
Outside the enclosure: IP67
*5
Inside the enclosure: IP2X
External dimensions
(Excluding USB environmental
protective cover)
241(9.49)(W) 190(7.48)(H) 52(2.05)(D)[mm](inch)
Panel cutting dimensions 227(8.94)(W) 176(6.93)(H)[mm](inch)
Weight 1.9 kg(4.2lb) (mounting fixtures are not included)
Compatible software package
GT1565-VTBA:
GT Designer3 Version1.01B or later
GT Designer2 Version2.04E or later
GT1565-VTBD:
GT Designer3 Version1.01B or later
GT Designer2 Version2.17T or later
GT Designer3 Version1.01B or later
GT Designer2 Version2.17T or later
Item Model Function version
GT1565
GT1565-VTBA A
GT1565-VTBD A
To Next Page
