13 - 84
13.10 Special Data Information
13.10.3 Special data information display example
13.10.3 Special data information display example
Remark
Folders and files displayed
For the folders and files displayed, refer to the following.
13.1.5 Display file
Number Item Description
(1) Select drive
The drive by which a file or folder is displayed can be selected.
When the CF card is not installed, [A: Built-in CF card] and [B: Memory card] are not displayed.
(2) Kind
Indicates whether the displayed name is file or folder.
In the case of file, displays the extension; in the case of folder, displays "DIR".
(3) Name
Displays the name of special data in the selected drive.
When the name exceeds 18 characters, the 19th and later characters are not displayed.
The special data being monitored on the GOT is preceded by "*%".
(4) Path name Displays the path name of drive /folder which is currently displayed.
(5) Size Displays the size of the file displayed in Name.
(6) Date and time Displays the date and time when each file is installed.
(7) The size of drive
Displays the size in use and the entire size of the drive which is selected by drive selection.(Only
the size in use is displayed when selecting the C drive.)
(8) Operation switch
Displays switch of each function executable in the Special data information (download, upload,
etc.).
(9)
Number of folders and
files
Displays the total number of displayed files and folders.
(1)
(2) (3) (4) (5) (6)
(7)
(8) (9)
