13 - 50
13.7 Advanced Recipe Information
13.7.4 Advanced recipe information operation
2 G1P CSV conversion operation, G1P TXT conversion operation
Advanced recipe file (G1P file) is converted to CSV file or Unicode text file that can be displayed/edited
on personal computer.
1 Touch and select the G1P file which is to
be converted to CSV file or Unidcode
text file.
2 Touch the following button in
accordance with destination file type.
• CSV file : button
• Unicode text file : button
3 Select the target folder.
(Selecting a folder is not needed for
outputting directly below the drive.)
(Example: Dialog if the button is touched.)
4 If touch the button, the dialog
shown left is displayed.
Touch the button.
(While executing, "Processing..."
message appears on the screen.)
(Continued to next page)
G1P->TXT
G1P->CSV
To Next Page
