Mitsubishi GOT1000 GT15 User Manual

2.2 Component List
2.2.2 Option
2 - 7
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND SETTINGS
5
EMC AND LOW VOLTAGE DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
2.2.2 Option
Communication unit (Sold separately)
Product name Model name Description
Bus connection unit
GT15-QBUS
For QCPU (Q Mode)/Motion
controller CPU (Q Series)
connection (standard model)
For last GOT, Number of IN side
connectors: 1
GT15-QBUS2
For intermediary and last GOT,
Number of IN and OUT side connectors: 1
for each side
GT15-ABUS
For A/QnACPU/Motion
controller CPU (A Series)
connection (standard model)
For last GOT, Number of IN side
connectors: 1
GT15-ABUS2
For intermediary and last GOT,
Number of IN and OUT side connectors: 1
for each side
GT15-75QBUSL
For QCPU (Q Mode)/Motion
controller CPU (Q Series)
connection (slim model)
For last GOT, Number of IN side
connectors: 1
GT15-75QBUS2L
For intermediary and last GOT,
Number of IN and OUT side connectors: 1
for each side
GT15-75ABUSL
For A/QnACPU/Motion
controller CPU (A Series)
connection (slim model)
For last GOT, Number of IN side
connectors: 1
GT15-75ABUS2L
For intermediary and last GOT,
Number of IN and OUT side connectors: 1
for each side
Serial communication
unit
GT15-RS2-9P For RS-232 interface connection, connector type
GT15-RS4-9S For RS-422 interface connection, connector type
GT15-RS4-TE For RS-422 interface connection, terminal block type
Ethernet
communication unit
GT15-J71E71-100 Ethernet (100Base-TX/10Base-T) unit
MELSECNET/H
communication unit
GT15-J71LP23-25 Optical double loop unit
GT15-J71BR13 Coaxial bus unit
MELSECNET/10
communication unit
GT15-75J71LP23-Z
Optical loop unit
(A9GT-QJ71LP23 + GT15-75IF900 set)
GT15-75J71BR13-Z
Coaxial bus unit
(A9GT-QJ71BR13 + GT15-75IF900 set)
CC-Link IE Controller
Network
communication unit
GT15-J71GP23-SX Optical loop unit
CC-Link IE Field
Network
communication unit
GT15-J71GF13-T2 Intelligent device station unit
CC-Link
communication unit
GT15-J61BT13
Intelligent device station unit
CC-LINK Ver. 2 compliant
GT15-75J61BT13-Z
Intelligent device station unit
(A8GT-J61BT13 + GT15-75IF900 set)
Interface converter unit GT15-75IF900 Conversion unit for GOT-A900/GOT800 series communication unit
Serial multi-drop
connection unit
GT01-RS4-M GOT multidrop connection unit

Mitsubishi GOT1000 GT15 Specifications

General

Display Size	10.4 inches
Display Type	TFT Color LCD
Resolution	640 x 480 pixels
Touch Panel Type	Analog resistive film
Power Supply	24V DC
Backlight	LED
Protection Rating	IP65 (front panel)
Interface	RS-232, RS-422/485, USB
Operating Temperature	0°C to 50°C
Memory	9 MB
Storage Temperature	-20 to 60°C
Display Colors	256 colors
