2.2 Component List
2.2.2 Option
2 - 13
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND SETTINGS
5
EMC AND LOW VOLTAGE DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
Connection cables for HITACHI PLCs (Sold separately)
Connection cables for FUJI PLCs (Sold separately)
Connection cables for PANASONIC INDUSTRIAL DEVICES SUNX PLCs (Sold separately)
Product
name
Model name Description
RS-232
Cable
GT09-C30R21301-9S Cable length 3m
For connecting GOT to HITACHI communication module
(LQE560/LQE060/LQE160)
RS-422
Cable
GT09-C30R41301-9S Cable length 3m
For connecting GOT to HITACHI PLC (LPQ510) and
communication module (LQE565/LQE165)
GT09-C100R41301-9S Cable length 10m
GT09-C200R41301-9S Cable length 20m
GT09-C300R41301-9S Cable length 30m
Product
name
Model name Description
RS-232
Cable
GT09-C30R21003-25P Cable length 3m
For connecting GOT to FUJI RS-232C interface card(NV1L-
RS2), RS-232C/485 interface capsule(FFK120A-C10), and
general-purpose interface module(NC1L-RS2/FFU120B)
RS-422
Cable
GT09-C30R41001-6T Cable length 3m
For connecting GOT to FUJI RS-232C/485 interface
capsule(FFK120A-C10) and general-purpose interface
module(NC1L-RS4/FFU120B)
GT09-C100R41001-6T Cable length 10m
GT09-C200R41001-6T Cable length 20m
GT09-C300R41001-6T Cable length 30m
Product
name
Model name Description
RS-232
cable
GT09-C30R20901-25P Cable length 3m
For connecting GOT to PANASONIC INDUSTRIAL
DEVICES SUNX RS422/232C conversion adapter
GT09-C30R20902-9P Cable length 3m
For connecting GOT to the tool port or RS232C port of
PANASONIC INDUSTRIAL DEVICES SUNX PLC, computer
communication unit
GT09-C30R20903-9P Cable length 3m
For connecting GOT to the RS232C port of PANASONIC
INDUSTRIAL DEVICES SUNX PLC
GT09-C30R20904-3C Cable length 3m
For connecting GOT to the RS232C port of PANASONIC
INDUSTRIAL DEVICES SUNX PLC

Mitsubishi GOT1000 GT15 Specifications

General

Display Size	10.4 inches
Display Type	TFT Color LCD
Resolution	640 x 480 pixels
Touch Panel Type	Analog resistive film
Power Supply	24V DC
Backlight	LED
Protection Rating	IP65 (front panel)
Interface	RS-232, RS-422/485, USB
Operating Temperature	0°C to 50°C
Memory	9 MB
Storage Temperature	-20 to 60°C
Display Colors	256 colors
